Wire Cut EDM Machine 5 Axis Servo

Product Description

High-Precision CNC Wire Cut EDM Machine Advanced 5-Axis System with Patented Technologies

Unlock next-level accuracy and performance with our state-of-the-art CNC Wire Cut EDM Machine, engineered for demanding industrial applications. This model combines innovative patented systems, robust construction, and intelligent automation to deliver unmatched cutting precision and reliability.

Key Features & Technologies:

Double Direction Wire Tension System (Patented)
Ensures optimal wire tension control in both directions, reducing wire breakage and enhancing cut consistency.

Thermal Cycle Pump (Patented Cooling Technology)

Fanless heat dissipation system increases energy efficiency, minimizes dust entry, reduces noise, and extends machine life.

Optimized Machine Bed Design
Finite Element Analyzed (FEA) bed structure ensures rigidity and minimal precision error for high-stability machining.

Robust T-shaped Frame
Made from high-grade 250 gray cast iron and treated for long-term dimensional stability and vibration damping.

Advanced Taper Cutting Capability
12 taper cutting range with dedicated brass WEDM taper system (U/V Axis) for intricate angled cuts.

Four-Axis Pitch Error Compensation
Ensures dimensional precision on X, Y, U, and V axes by eliminating cumulative positioning errors.

Five-Axis Direct Servo Motion System
Includes:

• Panasonic Servo Motors (X & Y)

• Taiwan PMI Linear Guides

• Five-Axis Precision Ball Screws

• Z-Axis Motor with Braking for Safety

Autocut 10.1 CNC Controller
Smart user interface with integrated 5-axis compensation, reverse pitch control, electric Z-axis lifting with memory, and user-friendly navigation.

Automated Wire Handling

• Molybdenum Wire Tension Control with automatic release to prevent fatigue

• Automatic Wire Loading for setup ease

• V-Groove Power Blocks for simplified wire changes

Built-in Safety Protections

• Digital, electronic & mechanical limits

• Tension monitoring

• Drum stroke protection

• Auto shutdown for broken wire & shorts

• Power failure memory resume

• Edge-stop for wire spool control

Industrial Control System
Equipped with industrial-grade PC, portable control box, and branded Dell monitor for clear visibility and reliable operation.

150L Dual-Pump Filtration System
Maintains clean dielectric fluid for smooth, high-precision cutting and extends fluid life.

Automatic Oil Lubrication System

Ensures longevity and optimal performance of moving parts.

Precision Wire Nozzles
Guarantees stable and accurate wire positioning during operation.

Enclosed Splash Guard + LED Illumination
Maintains a safe, clean workspace with excellent visibility.

Applications:

Perfect for mold & die industries, aerospace components, precision tooling, medical parts, automotive, and intricate part machining requiring high tolerances.

Why Choose This Machine?

Patented Technologies
Advanced 5-Axis Control
Industrial Durability
Automation-Ready
Designed for Long-Term Performance
